EAP101

$240.00

Wi-Fi 6 Indoor Access Point

  • Concurrent Dual-Band 2.4GHz & 5GHz
  • 2×2:2 UL MU-MIMO
  • Support BLE/ Zigbee
  • 1 x 2.5GbE PoE WAN
  • 2 x GbE LAN
  • Support ecCLOUD
Compare

Size and packaging guidelines

Fermentum scelerisque hendrerit parturient nullam enim lobortis litora parturient dictumst.

Potenti a quisque tincidunt venenatis adipiscing parturient fermentum nisl tincidunt amentu.

Scelerisque conubia lobortis a condimentum ad eleifend dui integer maecenas habitant nostra.

Specification Chair Armchair Sofas
Height 37" 42" 42"
Width 26.5" 32.5" 142"
Depth 19.5" 22.5" 24.5"
Assembly Required No No Yes
Packaging Type Box Box Box
Package Weight 55 lbs. 64 lbs. 180 lbs.
Packaging Dimensions 27" x 26" x 39" 45" x 35" x 24" 46" x 142" x 25"
Size Guide
Category:
Description

EAP102 is an enterprise-grade, concurrent dual-band Wi-Fi 6 indoor access point. EAP102 supports 4 x 4 : 4 uplink and down link MU-MIMO between the AP and multiple clients, with up to 2.9 Gbps aggregated data rate. EAP102 is equipped with Bluetooth Low Energy (BLE) radio enabling value-added applications such as iBeacon.

EAP102 can be operated as standalone mode or managed by Edgecore ecCLOUD.

Standards:
• 802.11ax (Wi-Fi 6)
• Concurrent dual-band 2.4 GHz & 5 GHz

Radio Chains:
• 2.4 GHz: 2 x 2
• 5 GHz: 4 x 4

Spatial Streams:
• 2.4 GHz: 2; MU-MIMO support
• 5 GHz: 4; MU-MIMO support

Aggregate Conducted Transmit Power:
• 2.4 GHz: Up to 23 dBm
• 5 GHz: Up to 26 dBm

Channelization:
• 2.4 GHz: 20 / 40 MHz
5 GHz: 20 / 40 / 80Mhz

Frequency Range:
• 2.400 – 2.483 GHz
• 5.150 – 5.850 GHz

Operating Channels:
• 2.4 GHz: 1 –11 (US), 1 –13 (Europe), 1 –13 (Japan)
• 5 GHz: 36 –165 (US), 36 –140 (Europe), 36 –144 (Japan)

ESSIDs:
• Up to 16 per radio (32 total)

Additional information
Weight 0.65 kg
Dimensions 19.5 × 19.5 × 3.9 cm
